Hydraulic 4FT Wood Log Rounding Debarker Machine with Chipper
1. Fearures
Log rounding debarker is used for peeling off the log skin and make the raw log to be round,after debarking it will be easy for the peeling lathes to peel and the veneer thickness will be even without big variation,also can increase the peeling lathes working life.One set debarker can work with two sets of peeling lathes, it can save labor.
2. Technical Parameters
| DEscriptION | UNIT | PARAMETERS |
| Length of peeler log | mm | 970mm-1270mm-1400MM |
| Diameter of peeler log | mm | Maximum 550mm-Core 50mm |
| Rotary cutting thickness range | mm | 1mm-4.0mm |
| Linear speed of host machine | m/min | 60m |
|
Main motor power Auxiliary motor power |
KW |
11KW+7.5KW Feeding 5.5KW Hydraulic pump 5.5Kw(Air cooling device) Waste chipper 11KW(Optional) |
| Reducer type selection | #350 Heavy Model | |
| Rollers specification | mm | Ø150mm x 1500mm(Harden chroming thicker) |
| Machine weight | Kgs | 3500Kgs |
3. More Picture
