1.Product brief introduction
8 feet numerical control rotary cutting AIO veneer peeling machine(Aggravation) is used to process wood segments of a certain length and diameter into continuous veneer strips for the production of plywood, fine wood upper boards and other wood-based panel veneers. The main technical parameters of the rotary cutting machine are that it can be processed Maximum length and diameter of wood segments.
8 feet veneer peeling machine is used for peel the wood into face veneers. Face veneers can be laminated on the core veneers, to make the plywood better. Spindle-less plywood veneer peeling machine is most welcomed among plywood machinery.Heavy duty veneer peeling machine has high configuration, to guarantee the veneer quality. This model is suitable for hard wood, such as Eucalyptus,etc.
8 feet heavy duty double row power peeling machine with spindle is often applied to ALVA assembly veneer peeling rotary cutting line，it brings great convenience,the appearance of CNC 8 feet veneer peeling machine not only improves the quality and precision of the production of veneer, but also greatly improves the production efficiency and the degree of automation of the whole machine. The 8 feet veneer peeling machine is one of the main equipment for the production of plywood.
2.Product parameter list
| Model | ALVA-VP-8FT01 |
ALVA-VP-8FT02 |
| Max peeling length | 2600mm | 2600mm |
| Max cutting diameter | 500mm | 500mm |
| Thickness range | 0.5mm-2.6mm | 0.35mm-5mm |
| Peeling knife | 2700*180*16mm | 2700*180*16mm |
| Cutting knife | 2700*140*12.7mm | 2700*140*12.7mm |
| Core diameter of remaining | 32-40mm | 32-40mm |
| Diameter of guide screw | 90mm | 90mm |
| Single roller motor | 2*7.5kW | 2*7.5kw（servo motor） |
| Double roller motor | 2*7.5kw（servo motor） | 2*7.5kw（servo motor） |
| Feeding motor | 11kw（servo motor） | 11kw（servo motor） |
| Cutting motor | 5.5kw（servo motor） | 5.5kw（servo motor） |
| Conveyor motor | 2.2kw | 2.2kw |
| Total power | 48.7kw | 48.7kw |
| Speed | 20M-80M/minute(adjustable) | 40M-80M/minute(adjustable) |
| Weight diameter | 10500kgs |
|
| Overall dimension | 6750*2000*1500mm | 6750*2000*1500mm |
3.Product Advantage：
The rotary cutting board is combined into one, which improves the utilization rate of the site and labor. It adopts advanced high-strength wear-resistant screw and screw drive and multi-functional numerical control box, which is easy to operate and automatically cut skin, low maintenance rate, labor saving and material saving. And make the precision of the veneer finger quality stable and reliable. Suitable for miscellaneous wood, eucalyptus, maple, pine, etc.
4.Product picture
5.Product link
https://www.youtube.com/channel/UC6yieZ2S5_1MNK1qtDwJFDg
6.Main features
1) Using microcomputer control system, the operation is easy and simple
2) Driven by servo motor and precision screw feed.
3) It is equipped with touch screen , very convenient to change thickness and other parameters .
7.Packaging & Shipping
1) Packing: Nude packing.
2) Port of shipment: Qingdao Port or according to the client request.
8.Our Services
Before-Sales Service
* Provide the free consultation of the equipment.
* Provide the standard device and the flow chart.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory. Welcome to visit our factory
After-Sales Service
* Inspect the machine before leaving the factory.
* Training how to install the machine.
* Training how to use the machine.
* Engineers available to service machinery oversea.
9.Frequently Asked Question
1). Q:A FACTORY OR A DEALERS?
A:We are a factory who have been producing plywood machinery for 20 years.
2). Q:QUALITY CONTROL?
A: Each machine will be tested three times before delivery.
3). Q:DELIVERY TIME?
A: 30-90 days upon receiving deposit.
4). Q:Factory Layout Design?
A:We have engineer team to make layout drawing for customers for free.
5). Q: After-sales Service?
A: We have technician team to help customers on installation.
6). Q:WARRANTY?
A: One-year warranty and we supply parts and service all the time.
7). Q:PAYMENT TERMS?
A: T/T accepted.
8). Q:MOQ?
A: The MOQ is 1 set.
9). Q: How to go to your factory?
A: There's three flights per day from SHANGHAI, one flights per day from GUANGZHOU. It takes 50 minutes from airport ( LINYI AIRPORT ) to our factory.
