Click the picture to view the original image
1. The machine is usually designed and customized according to user 's requirement (such as veneer size, drying capacity, workshop space ).
2. Mainly used to remove extra moisture from the veneer.
3. The heat medium can be thermal oil or hot steam.
4. Roller gear drive system help keep the dryed veneer smooth and flat.
5. Speed adjustable according to different veneer MC and veneer thickness.
Technical Specifications
Capacity: 1cbm/hour ~ 10cbm/hour.
Working decks: 1~6decks.
Working Width:1.4m~5m
Veneer Thickness range: 1.5mm~4.5mm.
| Model | BG183 |
| Working decks | 2 decks |
| Working width | 2650mm |
| Length of heating section | 2000mmx5 |
| Length of cooling section | 2000mm x 1 |
| Conveyor speed | 2~15m/min |
| Drying capacity | 1.2cbm/hour |
| Veneer Thickness | 0.5~1.5mm |
| Final Moisture content | 8~12% |
| Heating motor power | 37.5kw |
| Cooling motor power | 2.2kw |
| Conveyor motor power | 8kw |
| Heating medium | Hot steam or Thermal Oil |
| Machine weight | 22Tons |
