Mechanical spindle face veneer rotary peeling machine
Click the picture to view the original image
Product： Mechanical spindle face veneer rotary peeling machine
Brand： FOCUSMACH
Log diameter： 1700mm
Log length： 2700MM
Veneer thickness： 0.18-2.6MM
Valid Date： Long term effective
Last update： 2022-06-25 09:14
  Inquiry price
Detailed information
Machine name
 Mechanical Spindle Face Veneer Rotary Peeling Machine
Machine model
 FMBXQ1827/1700LSDK
Max. peeling logs diameter
 1700mm
Max. peeling logs length
 2700mm
Veneer thickness range
 0.18-2.6mm
Main motor power
 30Kw
Logs two ends fasten motor power
 4Kw x 2sets
Fast forward & backward motor power
 1.5Kw
Knife adjustment motor power
 1.1Kw
Hydraulic pumping station motor power
 0.75Kw
Logs pressure roller motor power
 1.1Kw
Logs lifting motor power
 3Kw x 2 sets
Machine overall dimension
 6000 x 2300 x 2600mm
Machine weight
 8500Kgs
