YDM Industrial Grade 2513 Flatbed Printer
Click the picture to view the original image
Product: YDM Industrial Grade 2513 Flatbed Printer
Valid Date: Long term effective
Last update: 2024-05-14 11:27
  Inquiry price
Detailed information
Print Technology
Printer Model 2513 UV Printer
Max. Print size 2500*1300mm
Print head model Toshiba CE4M,Ricoh G5,G6
Qty of Printhead 4-16 pcs/2-8pcs
Print Direction Unidirectional /Bi-directional
Print head height Semi-Automatic height adjustment (option Auto)
Print head cleaning Manual cleaning system
Print resolution Toshiba CE4M4 pass: 600*600 dpi
6 pass: 600*900 dpi
8 pass: 600*1200 dpi
RICOH G54 pass: 720*600 dpi
6 pass: 720*900 dpi
8 pass: 720*1200 dpi


Ink System
Ink type UV ink
Ink color CMYK/ CMYK+W/CMYK+W+V/2*CMYK+2*W+2*V
Ink tank volume 3.5L
Ink supply Negative ink supply system
Drying type imported LED lamp curing
White ink stirring Available
While ink circulation Available
Media
Media type Acrylic/ aluminum/ ceramic/ foam board/ glass/cardboard & others
Max.media thickness 100mm or customized
Operation
Operation Language Chinese / English
Operation system Windows XP/ Windows 7/Windows 10
Operation platform Completed vacuum adsorption platform
Operation Environment Temperature:20℃~28℃ Humidity:40% RH~60% RH
Computer configuration System:XP,win7,win10,32/64
CPU:≥ Intel i5
RAM: ≥8GB
Hard Disk: SATA 500G, NTFS
CD Rom: DVD recordable
Space for Disk C : ≥100 G
Others
RIP software UnitedFancy/Printfactory( option :Photoprint)
Interface LAN
Color control Comply with ICC standards with curve and density adjustment function.
Image format TIFF,JPEG,POSTscript3,PDF
Power supply AC220V,50/60HZ
Power consumption 3.5 KW
Noise Standby < 32dB Working < 65dB
The UV lamp LED curing, 50000 hours long lifetime, water cooling

Product Details

Vacuum Platform

Antioxidative vacuum platform with double teflon coating treatment,light weight with high hardness surface,scrath resistance and corrosion resistance,And mechanical alignment point to make sure the consistent media placement accurately.

Carriage

Newly designed lightweight carriage, OEEPO or AP&T static eliminator, temperature controller,  head cleaning button and carriage anti-collision device to ensure more stable and accurate printing

Humanized Operation Design

The emergency stop button can protect the safety of personnel more effectively.
Convenient operation buttons make it easier for operators to operate.
6 PCS zone buttons, can get greater adsorption power and save electricity

Large Volume Ink Tank

The 3.5 L large-volume ink tanks are equipped with ink lack alarm, which can meet the continuous production of 24 hours.

OEM Available Always For You based On Our Rich Experience In Uv Printer Since 2005’S.

FOR printer, according your needs, you can choice install Epson Series print head(such as F 1080-A1, L1440-A1, F1440-A1 or I 3200-U1 print head), Toshiba CE4M or RICOH G5/G6 print head.

Epson Print Head

Toshiba CE4M Print Head

RICOH G5 Print Head

Whether you need a high-precision printer or fast printing printer, we can customize the printing solution that meet your needs.

CMYK W V can be printed at the one time,UV varnish is cured by passing it under an ultraviolet light which quickly dries and hardens the varnish, creating a super high gloss varnish and offers the highest protection between varnish, aqueous and UV. Varnishing a product with UV will make it look much more professional, as well as making it much more attractive.Varnishing increases the perceived quality of the product. In addition, it is an economical and user-friendly process that can be easily applied by adding spot finishes or additional processes to the entire sheet. It can be manipulated to achieve the desired result

Productive Process

Machine Assembly&Testing

01 Machine Dynamic Design

02 Raw Materials Preparation

03 Nc Sawing Processing

04 Machine Modular Cutting Processing
