The blackbody calibration source is a standard for infrared radiation. It is widely used in the technical index test of the process test and the qualification test during the development of the infrared detector. It can complete the response uniformity, response curve and death of the photosensitive surface of the infrared focal plane device. In the test of parameters such as element pixels. At the same time, the area source blackbody radiation source is the core equipment of the infrared imaging prism collimation device, and it cooperates with the infrared collimation optical system and infrared target to complete the key technical index test and performance evaluation of the infrared imaging system. It can meet the testing requirements of infrared imagers in my country's newly developed infrared imaging guided weapons, and can meet the testing requirements of infrared thermal imaging cameras that are widely used in medical, construction, security monitoring, environmental testing and other industries.
Not greater than 0.15℃ and 0.15%T(bigger one in two)
T is the radiation source temperature（Within 10min）
±(0.2~0.6)℃ （2/3 center area）
①Support 232 communication
②Adjustable emissivity（Adjustable between 0.95~0.99）
Model
DY-HT2M-150
Temperature Range
RT+5℃~500℃
Control Mode
Touch Screen
Temperature Resolution
0.1℃/0.01℃
Temperature Control
PID Automatic Control
Radiating Surface
φ150mm
Emissivity
≥0.95
Temperature Stability
Temperature Uniformity
Power Supply
220V AC 50/60Hz
Wire Line Diameter
≥1.5㎡
Power
800W
Dimension(L×W×H)
240mm×215mm×370mm
Weight
8.0Kg
Environment
22℃±3℃;15%-65%RH;
Optional Features
